Table 4 ECO/Bypass Mode Specifications
Bypass Mode
INVERTER MODEL
3KW
5KW
Input Voltage Waveform
Sinusoidal (utility or generator)
Low Loss Voltage
176Vac± 7V
Low Loss Return Voltage
186Vac± 7V
High Loss Voltage
280Vac± 7V
High Loss Return Voltage
270Vac± 7V
Nominal Input Frequency
50Hz / 60Hz (Auto detection)
Low Loss Frequency
46(56)± 1Hz
Low Loss Return Frequency
46.5(57)± 1Hz
High Loss Frequency
54(64)± 1Hz
High Loss Return Frequency
53(63)± 1Hz
Table 5 General Specifications
INVERTER MODEL
3KW
5KW
SCC type
MPPT
Parallel-able
YES
Communication
RS232 and Bluetooth
Safety Certification
CE
Operating Temperature
Range
0°C to 55°C
Storage temperature
-15°C~ 60°C
Humidity
5% to 95% Relative Humidity (Non-condensing)
Dimension
(D*W*H), mm
140 x 303 x 525
Net Weight, kg
13.0
13.5
