Bypass/ECO Mode
The unit will provide output
power from the utility. PV
energy and utility can charge
batteries.
Charging by utility
No charging
Line Mode
The unit will provide output
power from the mains. It will
also charge the battery at
line mode.
Charging by utility and PV energy.
Charging by utility.
Battery Mode
The unit will provide output
power from battery and PV
power.
Power from battery and PV energy.
PV energy will supply power to the loads and
charge battery at the same time.
Power from battery only.
