MPP Solar 5KW User Manual

33
Table 2 Battery Mode Specifications
INVERTER MODEL
3KW
5KW
Rated Output Power
3KVA/3KW
5KVA/5KW
Output Voltage Waveform
Pure Sine Wave
Output Voltage Regulation
230Vac± 5%
Output Frequency
50Hz or 60Hz
Peak Efficiency
90%
Overload Protection
5s@≥150% load; 10s@105%~150% load
Surge Capacity
2* rated power for 5 seconds
Nominal DC Input Voltage
24Vdc
48Vdc
Operating Range
20Vdc -34Vdc
40Vdc -66Vdc
Cold Start Voltage
23Vdc
46Vdc
Low DC Warning Voltage
22.5Vdc
22.0Vdc
45.0Vdc
44.0Vdc
@ load < 50%
@ load ≥ 50%
Low DC Warning Return Voltage
23.5Vdc
23.0Vdc
47.0Vdc
46.0Vdc
@ load < 50%
@ load ≥ 50%
Low DC Cut-off Voltage
21.5Vdc
21.0Vdc
43.0Vdc
42.0Vdc
@ load < 50%
@ load ≥ 50%
High DC Recovery Voltage
32Vdc
64Vdc
High DC Cut-off Voltage
34Vdc
66Vdc
No Load Power Consumption
<75W
<75W
