MPP Solar LV2424 User Manual

21
Display Setting
The LCD display information will be switched in turns by pressing “UP” or “DOWN” key. The selectable
information is switched as below order: input voltage, input frequency, PV voltage, charging current, battery
voltage, output voltage, output frequency, load percentage, load in Watt, load in VA, load in Watt, DC
discharging current, main board firmware version and SCC firmware version.
Select item
LCD display
Input voltage and output voltage
(Default Display Screen)
Input Voltage=230V, output voltage=230V
Input frequency and output frequency
Input frequency=50.0Hz, output frequency=50.0Hz
Battery voltage and output voltage
Battery Voltage=27.0V, output voltage=230V
Battery voltage and load percentage
Battery Voltage=27.0V, load percentage = 68%
