MICROPHONE (M1)
Themicrophoneisdevelopedespeciallyforin-caruse.Thelocationofthemicrophonesignificantlyinfluencestheacoustic
quality.Forarecommendationonlocatingthemicrophone,seethe“Installation”chapter.
Themicrophonehasa2positionalbuttonforadjustingitssensitivity.Pressthebuttononthemicrophonetoincreasethe
volumetotheothercaller.
SYSTEM CABLES SC2 AND SC3 (Optional)
SystemcableSC2connectsthehandsfreeunitwiththepowersupplyandtheignitionsystemandisusedformutingtheradio.
SystemcableSC3isusedforplug&driveinstallation.Itprovidespowersupplyviathecigarettelighter.
Bothsystemcablesaresuppliedwithchangeablefuses.Howtochangethefusesisindicatedintheillustrationbelow.

SYSTEM CABLE MB1 (Optional)
SystemcableMB1connectsthehandsfreeunitwiththepowersupply,theignitionsystem,themutesocketofthecarradio
andthe2frontcarspeakers.ItincludesthemuteboxwithrelaycomponentsandacablewithISOstandardsockets.Please
seethechapter“Installation”wheretheconnectiondiagramisshown.
SYSTEM CABLE PRO MUSIC 100 (Optional)
Thiscableconnectsthehandsfreeunitwiththepowersupply,theignitionsystem,themutesocket,thespeakersandthe
radioofthecar.ItalsoprovidesaconnectiontoyourMP3playerandantennacables.
Pleaseseethechapter“Installation”wheretheconnectiondiagramisshown.
Fuse
Fuse
