Resolution Photo 0,1 RPM (5 to 999.9 RPM).
Tacho 1 RPM (over 1,000 RPM).
Contact 0,1 RPM (0.5 to 999.9 RPM).
Tacho 1 RPM (over 1,000 RPM).
Surface 0.01 m/min.(0.05 -99.99 m/min.)
Speed 0.1 m/min. (over 100 m/min.)
(m/min.)
Surface 0.1 ft/min. (0.1 to 999.9 ft/min.)
Speed 1 ft/min. (over 1,000 ft/min.)
(ft/min.)
Accuracy (0.05% + 1 digit).
Samplin
g
Time Photo Tacho - 1 sec. /over 60 RPM.
Contact Tacho - 1 sec. /over 6 RPM.
Photo Tacho 50 to 150 mm/2 to 6 inch. (typical max.
Detecting 300mm/12 inch, depending upon ambient
Distance light).
Range select Automation.
Time base Quartz crystal.
Circuit Exclusive one-chip design microprocessor
LSI circuit.
Battery 4 x 1.5V AA ( UM-3 ) battery.
Operation 0 - 50 (32 - 122 ).
Temperature
Size 215 x 65 x 38 mm.
(8.5 x 2.6 x 1.5 inch).
Wei
g
ht 300g(0.66 LB)/including battery.
Accessories Carrying case ..................................1 PC.
Reflecting tape marks (600mm).......1 PC
RPM adapter (CONE).......................1 PC.
RPM adapter (FUNEL)......................1 PC.
Surface speed test wheel.................1 PC.
Operation manual ............................1 PC.
2
