Contents
Indoor Unit Installation ...........10
1. Installation location.................................10
2. Attach mounting plate to wall...............11
3. Drill wall hole for connective piping.....11
4. Prepare refrigerant piping ....................13
5. Connect drain hose.................................14
6. Connect signal cable...............................16
7. Wrap piping and cables..........................17
8. Connect indoor power wire...................17
9. Mount indoor unit...................................17
Outdoor Unit Installation ......
19
1. Installation location ..............................19
2. Install drain joint .................................. 20
3. Anchor outdoor unit ........................... 21
4. Connect signal and power cables .... 22
5
4
Safety Precautions .................................. 3
!
1
Accessories ............................................... 5
Parts Overview ......................................... 9
3
2
Installation Summary - Indoor Unit ...... 7
