INSTALLATION (continued)
If you find that you need to move the overall location of a zone, you can move a zone to
the left by decreasing the X value (note that X values may be negative in some cases).
Increasing the X value will move the zone to the right. Decreasing the Y value will move
the zone closer, while increasing it will move the zone farther away.
The new zone will show in yellow except when a vehicle is present. If a vehicle is
present in a zone, the color changes to red. When you are satisfied with the location of
your zone, click on SET ZONE DATA near the upper left of your screen. At this point,
the yellow zone will turn green, indicating that it is saved to memory. You will also
observe traffic again in the DATA DISPLAY and in the VEHICLE TABLE.
Repeat the previous steps as necessary to create additional zones.
We recommend observing traffic for a short while to observe that all zones are
operating as intended. BREAD CRUMBS may be beneficial for making these
observations. Make any adjustments to the dimensions of the zones if necessary. Any
zones being altered will turn back to yellow instead of green when no vehicle is present.
Click SET ZONE DATA to save your changes.
To save your setup to file, follow these steps:
• Click on SET ZONE DATA to store your setup in the INTERSECTOR
• Select FAVORITES on the Toolbar at the top of your internet browser.
• Select ADD TO FAVORITES, name the setup (possibly the direction of traffic at this
intersection such as Westbound), and create a new folder to store this favorite in,
such as the intersection name (Main and 1st street).
• You can also copy the website link from the address bar and paste it to a Word
document. This Word document can then be saved as a file. We recommend naming
the file with the intersection and direction name (MainFirstWestbound.doc).
When you are satisfied with your settings and ready to enter operational mode, click on
BACK at the upper left. Please note that if you haven’t clicked SET ZONE DATA, one or
more of your changes may not be saved.
INTERSECTOR
Microwave Motion and
Presence Sensor Installation Instructions
MS Sedco INTERSECTOR Installation Instructions Page 17 INTERSECTOR-1.9Uv092717
