CHANGING THE INTERSECTOR IP ADDRESS
Software for the INTERSECTOR and TCIB has been updated to allow the system to be IP
addressable. Any INTERSECTOR units shipped with rev K or later software are IP
addressable. Older units that have rev F software must be upgraded to be IP
addressable. For instructions on updating software, please contact MS Sedco.
WARNING: If you plan to change IP Addresses on the INTERSECTOR and TCIB
for use with a local network, please maintain a record of the new IP Addresses
and passwords. If you do not have access to the IP Addresses and passwords it
will be necessary to connect to the INTERSECTOR and TCIB to obtain this
information.
WARNING: If you are setting up an Ethernet switch or multi-port hub to access
the INTERSECTOR it is important to use a modified Ethernet cable between the
“Operational” port of the TCIB and the switch or hub. This cable should be
modified to ensure voltage is not transmitted to the switch or hub. Ethernet
Switch Safe cable is available from MS Sedco. To construct one of the cables it
is necessary to disable pins 4, 5, 7, and 8.
To change the IP addresses on the INTERSECTOR or TCIB, it is first necessary to know
the current IP addresses. The default IP Addresses are:
Default Addresses:
INTERSECTOR IP 192.168.0.100
TCIB card 192.168.0.98
TCIB gateway 192.168.0.1
Computer 192.168.0.99
Computer subnet mask 255.255.255.0
Computer Gateway 192.168.0.1
To find out which version of software the INTERSECTOR and TCIB has, follow these
instructions:
To verify the software version of the INTERSECTOR:
• Set laptop IP address to 192.168.0.99 in the LAN properties of the TCP/IP as shown
on pages 11 and 12 of the INTERSECTOR Installation Instructions. Connect laptop to
the TCIB “Laptop” port. Move INTERSECTOR Ethernet cable from “Operational” port
to “Setup” port. Access the default web page at address 192.168.0.100. Note that
if your sensor has rev K or later software, you will be prompted for a password.
The default password is “password”. The software version should be shown as
v1.9T, where T is the software revision. NOTE: If IP Addresses have previously been
changed, it will be necessary to use the new IP addresses to access the
INTERSECTOR.
!
!
INTERSECTOR Microwave Motion and
Presence Sensor Installation Instructions
MS Sedco INTERSECTOR Installation Instructions Page 23 INTERSECTOR-1.9Uv092717
