MAINTENANCE
No regular maintenance of the INTERSECTOR is required. During the installation and
setup of the INTERSECTOR, certain problems may occur. We have attempted to list
some common problems and possible solutions. If you need further assistance while
installing the INTERSECTOR, please contact MS Sedco Technical Support at (317)
842-2545.
INTERSECTOR
Microwave Motion and
Presence Sensor Installation Instructions
MS Sedco INTERSECTOR Installation Instructions Page 32 INTERSECTOR-1.9Uv092717
DESCRIPTION OF
PROBLEM
When the TCIB card is
plugged in the LED
lights do not light up:
LED lights are always
on:
Unable to see setup
page when computer is
connected:
Once Ethernet
connection is made, and
you see the Zone Setup
page on your PC you see
a message at the top of
the page that reads
“Sensor Error”:
SOLUTION
• Check for power to the TCIB board.
• Verify that traffic is present in detection zones. Move
Ethernet cable to setup port. Connect PC and verify
zone location and sensor aim.
• Prior to completion of setup the TCIB board will keep
LED lights on as a “constant call”. Ensure that Ethernet
cable is connected to operational port. Connect sensor
to computer and setup zones.
• Check to ensure that Ethernet cable is connected to
sensor
• Check to ensure that Ethernet cable is plugged into
Setup port and laptop is connected to laptop port of the
TCIB board
• With the INTERSECTOR installed and connected to your
PC the Ethernet LEDs on the PC should show
connection. One LED is connection and should stay on,
and the other is data which should blink.
• Ensure that laptop IP address is set to proper address
(as detailed on Page 7 of installation manual)
• Check LEDs on the TCIB card. If they are not on, the
TCIB card is not functioning.
• Check the Ethernet cable. Plug the cable from the sensor
into the operational Ethernet port on the TCIB and see
that the LEDs go out to ensure the sensor is functioning
properly and there is Ethernet communication.
• There is a problem with the sensor that cannot be
corrected in the field. Contact your distributor or MS
Sedco for further information.
