31
Settings Parameters
GB
Model 9010/9020 SIL
P8
Detector Sensitivity Reduction Warning
Possible settings: A: enabled, nA: disabled,
default: nA / disabled
CAL symbol is displayed if the detector signal during the calibration is below 50 % of the
signal achieved during previous calibration
P9
Display Actual Detector Signal (depends on connected detector / transmitter)
It displays actual Ux value in mV for passive detectors or value in mA for transmitters.
P10
Display Full Scale Delta Detector Signal at Calibration
It displays the calculated full scale delta Ux value (mV) for passive sensors or delta Ix value
(mA) for transmitters achieved during last calibration procedure.
P20
Save Current Settings as User Defaults
Saved user defaults can be reloaded in menu 53 P2
stor: save user channel parameters
sall: save all user parameters
