Table 10 – Parameters of Alarms tab page
Tab name
Alarm message
Description
Heel
Warning roll
Pop-up message of critical heel on the port or starboard
(indicated)
Port
Specification of max permissible heel value on the Port
Starboard
Specification of max permissible heel value on the Star-
board
Pitch
Warning pitch
Pop-up message of critical pitch on the port or starboard
(indicated)
Bow of the ship
Specification of max permissible pitch value on the Port
Stern
Specification of max permissible pitch value on the Port
Heave
Warning heave
Pop-up message of critical heave
Upper bound
Specification of max permissible value for submerg-
ence upper bound
Lower bound
Specification of max permissible value for submerg-
ence lower bound
Speed vessel
Warning the speed of
the vessel
Pop-up message of changed vessel speed, dissatisfying
with selected settings
Respecting
Respective of specified herein parameter, speed vessel
is measured (respective of ground or water)
Activation condition
Pop-up message (speed vessel higher/lower/within
range/ out of range)
Lower
Specification of min permissible value of vessel speed
Air temperature
Warning the air
temperature
Pop-up warning message of air temperature
Activation condition
Pop-up message (air temperature lower/higher/within
range/out of range)
Higher
Specification of max permissible value of air tempera-
ture
Water tempera-
ture
Warning the water
temperature
Pop-up warning message of water temperature
Activation condition
Pop-up message (water temperature
lower/higher/within range/ out of range)
Lower
Specification of min permissible value of water temper-
ature
Depth
Warning about the
depth
Pop-up warning message of depth
Starting point
Setting a starting point (surface, transducer, keel)
Activation condition
Pop-up message (depth lower/higher/within range/ out
of range)
Lower
Specification of min permissible value of depth
ОК
–
To confirm the select
Apply
–
To apply the selected settings
Cancel
–
To cancel the selected settings
