US Lochinvar ProtoNode FPC-N54 Guide 3
Quick Start Guide
1. Record the information about the unit. (Section 2.1 Record Identification Data)
2. Check that the ProtoNode and customer device COM settings match. (Section 2.3 Configuring Device
Communications)
3. If connecting to a serial device:
Connect the ProtoNode 3 pin RS-485 R1 port to the RS-485 network connected to each of the devices. (Section 2.4
Device Connections to ProtoNode)
4. If using a serial field protocol:
Connect the ProtoNode 3 pin RS-485 R2 port to the field protocol cabling (Section 2.5 Wiring Field Port to RS-
485 Serial Network).
5. Connect power to ProtoNode 3 pin power port. (Section 3 Power up the Gateway)
6. Connect a PC to the ProtoNode via Ethernet cable. (Section 4 Connect the PC to the Gateway)
7. Setup Web Server Security and login via web browser. (Section 5 Setup Web Server Security)
8. Use a web browser to access the ProtoNode Web Configurator page to select the profile of the device attached to
the ProtoNode and enter any necessary device information. Once the device is selected, the ProtoNode
automatically builds and loads the appropriate configuration. (Section 6 Configure the ProtoNode)
9. Ethernet Network: If using an Ethernet field protocol, use a web browser to access the ProtoNodeWeb Configurator
page to change the IP Address. (Section 6.4 Ethernet Network: Setting IP Address for the Field Network)
