4 Lochinvar ProtoNode FPC-N54 Guide US
Contents
1 Introduction 6
1.1 ProtoNode Gateway 6
2 Setup for ProtoNode 7
2.1 Record Identification Data 7
2.2 Point Count Capacity and Registers per Device 7
2.3 Configuring Device Communications 7
2.3.1 Confirm the Device and ProtoNode COM Settings Match 7
2.3.2 Set Node-ID for Any Device Attached to the ProtoNode 7
2.4 Device Connections to ProtoNode 8
2.5 Wiring Field Port to RS-485 Serial Network 8
2.6 Bias Resistors 9
2.7 Termination Resistor 10
3 Power up the Gateway 11
4 Connect the PC to the Gateway 12
4.1 Connecting to the Gateway via Ethernet 12
4.1.1 Changing the Subnet of the Connected PC 12
5 Setup Web Server Security 13
5.1 Navigate to the Login Page 13
5.2 Login to the FieldServer 13
5.3 Select the Security Mode 15
5.3.1 HTTPS with Own Trusted TLS Certificate 16
5.3.2 HTTPS with Default Untrusted Self-Signed TLS Certificate or HTTP with Built-in Payload Encryption 16
6 Configure the ProtoNode 17
6.1 Select Field Protocol and Set Configuration Parameters 17
6.2 Setting Active Profiles 18
6.3 Verify Device Communications 19
6.4 Ethernet Network: Setting IP Address for the Field Network 20
6.5 BACnet: Setting Node_Offset to Assign Specific Device Instances 21
6.6 How to Start the Installation Over: Clearing Profiles 21
7 Troubleshooting 22
7.1 Lost or Incorrect IP Address 22
7.2 Viewing Diagnostic Information 23
7.3 Checking Wiring and Settings 24
7.4 LED Functions 25
7.5 Factory Reset Instructions 25
7.6 Internet Browser Software Support 25
7.7 Taking a FieldServer Diagnostic Capture 26
8 Additional Information 27
8.1 Update Firmware 27
8.2 BACnet: Setting Network_Number for More Than One ProtoNode on the Subnet 27
8.3 Mounting 28
8.4 Certification 28
8.5 Physical Dimensions 29
8.6 Change Web Server Security Settings After Initial Setup 30
8.6.1 Change Security Mode 30
8.6.2 Edit the Certificate Loaded onto the FieldServer 31
8.7 Change User Management Settings 32
