Table 7: Horn & Condition Acknowledges
Sequencer (A)
Sequencer B
Comments
Horn Acknowledge:
(Push Button)
08906
08941
Coil - Write
(Momentary action is
necessary.)
Condition Acknowledge:
(Push Button)
08656
08683
Coil - Write
(Momentary action is
necessary.)
Table 8: User Configured Output (UCO) Relay Images
Output #
UCO#1
UCO#2
Output #
UCO#1
UCO#2
1
18705
18769
17
18737
18801
2
18706
18770
18
18738
18802
3
18707
18771
19
18739
18803
4
18708
18772
20
18740
18804
5
18709
18773
21
18741
18805
6
18710
18774
22
18742
18806
7
18711
18775
23
18743
18807
8
18712
18776
24
18744
18808
9
18713
18777
25
18745
18809
10
18714
18778
26
18746
18810
11
18715
18779
27
18747
18811
12
18716
18780
28
18748
18812
13
18717
18781
29
18749
18813
14
18718
18782
30
18750
18814
15
18719
18783
31
18751
18815
16
18720
18784
32
18752
18816
In the table above: 0 = Open 1 = Closed (Default Non-failsafe*)
* User Changeable Parameter - State may need to be reversed depending on usage.
Table 9: Particulate Status for AQGard
Sequencer (A)
Comments
Particulate Status:
40561
AQGard Users Only
0 = Normal , 1 = Flow Ok, Laser Bad, 2 = Flow Bad, Laser Ok, 3 = Flow
Bad, Laser Bad, 4 = Error
