MSA MultiGard 5000 - Page 8

Table 3: Points 1-32 Alarm States
Sensor 1 Sensor 2 Sensor 3 Sensor 4
Point # Trouble Warning Alarm Trouble Warning Alarm Trouble Warning Alarm Trouble Warning Alarm
1 14098 14099 14100 14610 14611 14612 15122 15123 15124 15634 15635 15636
2 14130 14131 14132 14642 14643 14644 15154 15155 15156 15666 15667 15668
3 14162 14163 14164 14674 14675 14676 15186 15187 15188 15698 15699 15700
4 14194 14195 14196 14706 14707 14708 15218 15219 15220 15730 15731 15732
5 14226 14227 14228 14738 14739 14740 15250 15251 15252 15762 15763 15764
6 14258 14259 14260 14770 14771 14772 15282 15283 15284 15794 15795 15796
7 14290 14291 14292 14802 14803 14804 15314 15315 15316 15826 15827 15828
8 14322 14323 14324 14834 14835 14836 15346 15347 15348 15858 15859 15860
9 14354 14355 14356 14866 14867 14868 15378 15379 15380 15890 15891 15892
10 14386 14387 14388 14898 14899 14900 15410 15411 15412 15922 15923 15924
11 14418 14419 14420 14930 14931 14932 15442 15443 15444 15954 15955 15956
12 14450 14451 14452 14962 14963 14964 15474 15475 15476 15986 15987 15988
13 14482 14483 14484 14994 14995 14996 15506 15507 15508 16018 16019 16020
14 14514 14515 14516 15026 15027 15028 15538 15539 15540 16050 16051 16052
15 14546 14547 14548 15058 15059 15060 15570 15571 15572 16082 16083 16084
16 14578 14579 14580 15090 15091 15092 15602 15603 15604 16114 16115 16116
17 16146 16147 16148 16658 16659 16660 17170 17171 17172 17682 17683 17684
18 16178 16179 16180 16690 16691 16692 17202 17203 17204 17714 17715 17716
19 16210 16211 16212 16722 16723 16724 17234 17235 17236 17746 17747 17748
20 16242 16243 16244 16754 16755 16756 17266 17267 17268 17778 17779 17780
21 16274 16275 16276 16786 16787 16788 17298 17299 17300 17810 17811 17812
22 16306 16307 16308 16818 16819 16820 17330 17331 17332 17842 17843 17844
23 16338 16339 16340 16850 16851 16852 17362 17363 17364 17874 17875 17876
24 16370 16371 16372 16882 16883 16884 17394 17395 17396 17906 17907 17908
25 16402 16403 16404 16914 16915 16916 17426 17427 17428 17938 17939 17940
26 16434 16435 16436 16946 16947 16948 17458 17459 17460 17970 17971 17972
27 16466 16467 16468 16978 16979 16980 17490 17491 17492 18002 18003 18004
28 16498 16499 16500 17010 17011 17012 17522 17523 17524 18034 18035 18036
29 16530 16531 16532 17042 17043 17044 17554 17555 17556 18066 18067 18068
30 16562 16563 16564 17074 17075 17076 17586 17587 17588 18098 18099 18100
31 16594 16595 16596 17106 17107 17108 17618 17619 17620 18130 18131 18132
32 16626 16627 16628 17138 17139 17140 17650 17651 17652 18162 18163 18164
Each register will present either a “0” or “1”. Where, 0 = Normal and 1 =
Condition Exists!
