MSA MultiGard 5000 - Page 9

Table 4: Flow Status
Point #
Sample Bypass Sample Bypass
1 18193 18257 18321 18353
2 18194 18258 18322 18354
3 18195 18259 18323 18355
4 18196 18260 18324 18356
5 18197 18261 18325 18357
6 18198 18262 18326 18358
7 18199 18263 18327 18359
8 18200 18264 18328 18360
9 18201 18265 18329 18361
10 18202 18266 18330 18362
11 18203 18267 18331 18363
12 18204 18268 18332 18364
13 18205 18269 18333 18365
14 18206 18270 18334 18366
15 18207 18271 18335 18367
16 18208 18272 18336 18368
17 18225 18289
18 18226 18290
19 18227 18291
20 18228 18292
21 18229 18293
22 18230 18294
23 18231 18295
24 18232 18296
25 18233 18297
26 18234 18298
27 18235 18299
28 18236 18300
29 18237 18301
30 18238 18302
31 18239 18303
32 18240 18304
System A
System B
Each register will present either a “0” or “1”. Where, 0 = Normal and 1 =
Condition Exists!
