3103-1001 Rev. 0 5
1.2 General Operating Specifications
Table 1.1: MultiGard 5000 System Enclosure Specifications
Area Classification
General Purpose for Non-Hazardous Areas
System Configuration
MultiGard
5000
8/16
MultiGard
5000
24/32
MultiGard 5000
Dual 8/Dual 16
Rating
NEMA 1
NEMA 1
NEMA 1
Dimensions*
in (mm)
Width
24 (610)
30 (762)
30 (762)
Height
30 (762)
30 (762)
30 (762)
Depth
12 (305)
12 (305)
12 (305)
Weight, lbs (kg)
150 (68)
150 (68)
175 (80)
*dimensions less options
Operator Interface:
MultiGard 5000 8 / 16 / 24 / 32 / D8 / D16 - 10.4" Diagonal Color TFT LCD Display
Power Requirements:
MultiGard 5000 8 / 16 / 24 / 32 / D8 / D16 - 15 Amp. @ 115 VAC, 60 Hz
Outputs:
Common Alarms - Form C contacts (SPDT), 250 VAC,
Contact Rating
 8 Amp. Resistive Load
 6 Amp Inductive Load
Optional User Configurable Output (“UCO”) Discrete Alarms - Form C contacts (SPDT), 250 VAC
Contact Rating
 10 Amp. Resistive Load
 7.5 Amp Inductive Load
Optional User Configurable Output (“UCO”) Solid State Outputs - 100 mA @ 24 Volts DC, Sinking
(Requires external 24 VDC power supply)
