3103-1001 Rev. 0
Sample text related to the dual MultiGard units.
This information can be ignored by users of single MultiGard units.
Users of MultiGard 5000 Dual 8 and MultiGard 5000 Dual 16 units should note the following rules
on using the same operator manual:
The same information content is provided on each screen across all models. The location of
some items may be different between the single and dual models.
Wherever dual MultiGard 5000 data is presented based on the number of sample points the
quantity will vary between 8 or 16 and be presented in a similar manner.
The phrases underlined and in quotes which lead to a description of an item still refer to the
original figures. In addition these items in the dual MultiGard 5000 system are specifically
labeled System A (SYS A) and System B (SYS B) to distinguish between the two separate
systems. Items common to the overall assembly do not use this designation.
When explicit labeling is not used the header text System A: and System B: are used.
Everything directly under these headers then applies to the system as labeled.
The relative position of System A grouped data is on the left. The relative position of System
B grouped data is on the right. Data common to the overall assembly is located in the center
or where space permits.
Any special notes and exceptions to these rules will be discussed in the appropriate section and
will be visually distinguished by the text box style as shown below.
