The RDD Overview screen consists of the following:
Due to a close similarity to the MultiGard 5000 Overview screen refer to Section 4.1.1 for a
description of any items not listed in this section.
"Sensor 1 P1-8" through "Sensor 4 P9-16" - A group of 8 HMI navigation buttons which change the
screen to view sensor data and alarming status. The bar overlaying the appropriate button(s) will
flash as an "off-page" indication whenever a condition exists that requires operator attention.
"Horn Silence" - When this RDD indicator appears the horn may be silenced by the operator by
pressing the Horn Silence button on the MultiGard 5000 System Overview display screen or by use
of an optional remote horn acknowledge switch wired in accordance with the Field Wiring Diagram.
See Chapter 5, Common Alarming for more details.
"Condition Acknowledge" - When this RDD indicator appears, any condition (trouble, warning, or
alarm) has occurred and may be acknowledged by the operator only at the MultiGard 5000
touchscreen. See Alarming, Chapter 5 for more details.
9.3.2 Gas Levels (and Alarming Status)
The Gas Levels and Alarming Status screen is identical to that described in Section 4.1.2.
.
9.3.3 Flow Status (Sample and Bypass)
The Flow Status screen is identical to that described in Section 4.1.3.
9.3.4 Auto Standardization
The Auto Standardization screen is identical to that described in Section 4.1.4 with one exception.
The ASTD trigger push buttons have been eliminated. These functions are only available at the
MultiGard 5000 touch-screen.
9.3.5 Sequencer Control (and Point Bypass Status)
The Sequencer Control and Point Bypass Status screen is identical to that described in Section 4.1.6
with two exceptions. The mode pushbutton has been replaced by a mode status indicator and the
step push button has been eliminated. The status indicator will show "Stepping Mode: Automatic"
or "Stepping Mode: Manual". Actual control of the sequencer is only available at the MultiGard
5000 touch-screen.
