MSA WORKMAN - Typical Applications and Accessories

MSA Workman® Tripod
11
US
2.3 Typical Applications
WARNING!
Do not use the Workman Rescuer for material handling.
Do not raise or lower a user with the Workman Rescuer except for in a rescue application.
The Workman Winch can be used to raise and lower a user; however, it is not a fall arrest device. When
using a Workman Winch to raise and lower a user, the user must also be connected to the Workman
Rescuer or other appropriate fall arrest device.
Failure to follow these warnings can result in serious injury or death.
Size when compacted for transport or storage:
Length (L): 63 in (1.9 m)
Outside Diameter (D): 10 in (0.3 m)
Interior distance (X) between feet when set up with:
Legs at maximum extension: 59 in (1.5 m)
Legs at minimum extension: 37 in (0.9 m)
Overall height (Y) to top of head when set up with:
Legs at maximum extension: 96 in (2.4 m)
Legs at minimum extension: 60 in (1.5 m)
Interior headroom height (H) when set up with:
Legs at maximum extension: 91 in (2.3 m)
Legs at minimum extension: 55 in (1.4 m)
Notes: Adding equipment at Workman Tripod head reduces headroom.
Using Workman Winch to lower material.
Worker attached to Workman Rescuer for fall arrest and emergency
retrieval.
