MSA Workman® Tripod
26
Fig. 9 Inspection locations
5.4 Corrective Action
When inspection reveals any of the identified conditions, the Workman Tripod must be immediately
removed from service and marked as “UNUSABLE” until destroyed or subjected to maintenance by
the user’s organization. Damage, excessive wear and/or aging are generally repairable by the factory.
If detected, immediately remove the Workman Tripod from use and mark it as “UNUSABLE” until
repaired. For final disposition, submit the Workman Tripod to a competent person who is authorized to
perform Formal Inspection. If there is any question as to repairability, contact MSA or a service center
authorized in writing by MSA before further use of the Workman Tripod.
A Bolt (quantity 4) E Hog ring (quantity 6)
B Large clevis pin (quantity 3) F Eye nut (quantity 4)
C Washer (quantity 8) G Small clevis pin (quantity 3)
D Jam nut (quantity 4)
A
B
C
C
D
E
E
F
G
