Table 1 – Colour codes of cable MS-33001
Connector
Terminal
S
IG
FR
D+
GC
K30 (starter)
K45 (starter)
Use the cable MS-33001 and wire kit (fig. 6) to test the voltage regulators separately from
alternator.
Figure 6. Wire kit for diagnostics of voltage regulators
For the diagnostics of the starter, use the cable MS-33001 and the cable for the connection of
the terminal 50 (fig. 7).
