15
Indicial notation Functional purpose Terminal
RVC(L)
(Regulated Voltage Control) Similar to SIG, but voltage
change ranges from 11.0 V to 15.5 V. Control signal is sent to L
terminal
C
(Communication) Voltage regulator input to control engine
operation block. Japanese cars
GC
G
RLO
(Regulated Load Output) Input to control stabilizing voltage
from 11,8 to 15 V (TOYOTA)
COM
(Communication) General term for physical interface,
alternator control and diagnostics. Protocols of use: BSD (Bit
Serial Device), BSS (Bit Syn- chronized Signal) or LIN (Local
Interconnect Network)
LIN
Direct indication on control interface and alternator
diagnostics, con- ducted under LIN protocol (Local
Interconnect Network)
DF
Output of voltage regulator F1; F2
F
FLD
67
P
Output of one of alternator stator windings. Used for
measuring alternator driving voltage
S
STA
Stator
W
(Wave) Output of one of alternator stator windings for
connection of tachometers in diesel engine cars
N
(Null) Output of average stator winding point. Usually used
to regulate alternator operability with mechanically
regulated voltage
by an indicator lamp
D (Dummy) Blank, no connection, mostly in Japanese cars
