Tips/Instructions
!
CAUTION
BAG-D
Use thread lock on screws M3x8.
Thrust bearings flange with bigger
hole inward, flange with smaller hole
outward.
Spindle spacer is a stepped washer,
please make sure that, the stepped
side faces BB 5x10x4.
Washer
3.1x8x1
MSH 50122
Spindle Spacer
MSH 50011
Spindle Spacer
MSH 50011
Washer
3.1x8x1
MSH 50122
Dumper main head 500
MSH 50202
HUB SIDE
BLADE SIDE
Hex Screw
M3x8 button head
MSH 50147
Hex Screw
M3x8
MSH 50110
18
