Hex Screw
M2.5x8
MSH 50103
Hex Screw
M2.5x6
MSH 50102
Hex Screw
M2x6
MSH 50098
Motor Mount
MSH 50028
Caution
Washer
2.6x6.5x1.5
MSH 50146
BAG-B
Hex Screw
M2.5x6
MSH 50102
Hex Screw
M2.5x8
MSH 50103
!
CAUTION
Use Thread lock on every screw
metal/metal such as screws
that keep the servo frame in place.
Battery plate
MSH 50148
Under plate
MSH 50149
BB 8x16x5
MSH 50032
Third BB support
MSH 50150
Carbon frame L
MSH 50151
Washer
2.6x6.5x1.5
MSH 50146
9
