18
Specifications
Continued from previous page
Internal Connectors
∙ 1x 24-pin ATX main power connector
∙ 2x 8-pin ATX 12V power connector
∙ 1x 6-pin PCIE power connector
∙ 6x SATA 6Gb/s connectors
∙ 4x M.2 slots (M-Key)
∙ 1x USB 3.2 Gen 2 10Gbps Type-C port
∙ 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2
USB 3.2 Gen 1 5Gbps ports)
∙ 2x USB 2.0 connectors (supports additional 4 USB 2.0
ports)
∙ 1x 4-pin CPU fan connector
∙ 1x 4-pin water-pump fan connector
∙ 6x 4-pin system fan connectors
∙ 1x Front panel audio connector
∙ 2x System panel connectors
∙ 1x Chassis Intrusion connector
∙ 1x 4-pin RGB LED connectors
∙ 2x 3-pin RAINBOW LED connectors
∙ 1x 3-pin CORSAIR LED connector
∙ 1x TPM module connector
∙ 1x Clear CMOS jumper
∙ 1x Power button
∙ 1x Reset button
Continued on next page
