19
Specifications
Continued from previous page
Back Panel
Connectors
∙ 1x Clear CMOS Button
∙ 1x Flash BIOS Button
∙ 1x PS/2 keyboard/ mouse combo port
∙ 4x USB 2.0 Type-A ports
∙ 1x HDMI port
∙ 2x USB 3.2 Gen 2 10Gbps Type-A ports
∙ 1x 2.5 Gbps LAN (RJ45) port
∙ 1x USB 3.2 Gen 2 10Gbps Type-A port
∙ 1x USB 3.2 Gen 2 10Gbps Type-C port
∙ 2x Wi-Fi Antenna connectors
∙ 5x audio jacks
∙ 1x Optical S/PDIF Out connector
LED Features
∙ 1x EZ LED Control switch
∙ 1x 2-Digit Debug Code LED
∙ 4x EZ Debug LED
I/O Controller NUVOTON NCT6687D-R Controller Chip
Hardware Monitor
∙ CPU/ System/ Chipset temperature detection
∙ CPU/ System/ Pump fan speed detection
∙ CPU/ System/ Pump fan speed control
Form Factor
∙ ATX Form Factor
∙ 12 in. x 9.6 in. (30.4 cm x 24.4 cm)
BIOS Features
∙ 1x 256 Mb flash
∙ UEFI AMI BIOS
∙ ACPI 6.1 , SMBIOS 2.8
∙ Multi-language
Continued on next page
