1-2
MS-6580 ATX Mainboard
Mainboard Specifications
CPU
h Supports Socket 478 for Intel
®
Pentium 4 processors
h Supports up to 3.06 GHz and higher speed
Chipsets
h Intel
®
845PE chipsets
- AGP 4x slot (1.5v only)
- FSB 533/(800 MHz) (refer to Appendix B for details on FSB 800MHz )
- Support DDR 200/266/333/(400) DDR technology (refer to Appendix B for
details on DDR400)
- Support 400/533 MHz Intel NetBurst micro-architecture bus
h Intel
®
ICH4 chipset
- AC’97 2.2 interface
- 6 USB 2.0/1.1 ports
- 2 channel Ultra ATA/100 Bus Master IDE controller
- SMBus 2.0 support
- Integrated LAN controller
Main Memory
h Supports two 184-pin DDR200/DDR266/DDR333/(DDR400) DIMMs (refer
to Appendix B for details on DDR 400)
h Supports Max. memory size of 2GB
Slots
h One AGP (Accelerated Graphics Port) 4x slot (support 1.5v only)
h Six PCI 2.2 32-bit Master bus slots (support 3.3v/5v)
On-Board IDE
h An IDE controller integrated in ICH4
h Support PIO, Bus Master and Ultra ATA66/100 operation modes
h Can connect up to four IDE devices
On-Board Peripherals
h On-Board Peripherals include:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and
2.88Mbytes
- 1 serial port connector COM A
