3-23
BIOS Setup
Onboard LAN
This setting controls the onboard LAN controller. Setting options: Disabled,
Enabled.
Load OnBoard LAN BIOS
This item is available for you to load the onboard LAN BIOS settings.
Setting options: Disabled, Enabled.
AC97 Audio
This item is used to enable or disable the onboard AC’97 (Audio Codec’97)
feature. Selecting Auto allows the mainboard to detect whether an audio de-
vice is used. If an audio device is detected, the onboard AC’97 controller will
be enabled; if not, the controller is disabled. Disable the function if you want to
use other controller cards to connect an audio device. Settings: Disabled and
Auto.
On-Chip IDE
Configuration
Settings in Windows XP/2000
(Maximum of 6 devices)
Settings in Windows 98/ME
(Maximum of 4 devices)
On-Chip ATA(s)
Operate Mode
Legacy Mode (not available)
ATA Configuration
P-ATA Only P-ATA+S-ATA
S-ATA Keep Enabled
Yes (not available)
P-ATA Keep Enabled (not available) (not available)
P-ATA Channel Selection
Both (not available)
Combined Mode Option
(not available)
* S-ATA 1st Channel /
P-ATA 1st Channel
S-ATA Ports Definition
P0-3rd. / P1-4th. P0-Master / P1-Slave
* When choosing S-ATA 1st Channel, you can use SATA1 & SATA2, IDE2.
When choosing P-ATA 1st Channel, you can use IDE1, SATA1 & SATA2.
