MSI 865PE Neo2-P Platinum Edition User Manual

A-5
Using 2-, 4- & 6-Channel Audio Function
Here it provides the Karaoke function which will automatically remove
human voice (lyrics) and leave melody for you to sing the song. Note that this
function applies only for 2-channel audio operation.
Just check the Voice Cancellation box and then click OK to activate the
Karaoke function.

MSI 865PE Neo2-P Platinum Edition Specifications

General

Chipset	Intel 865PE
Socket	Socket 478
Supported CPU	Intel Pentium 4/Celeron
Max Memory	4GB
Expansion Slots	1 x AGP 8X, 5 x PCI
Form Factor	ATX
Audio Chipset	Realtek ALC655
LAN Speed	10/100Mbps
Memory Slots	4
Storage Interface	ATA 100/66/33, SATA 1.5Gb/s
Audio Channels	6
LAN Chipset	Realtek RTL8100C
Dimensions	305mm x 245mm
USB Ports	8 x USB 2.0
