MSI Feature
MS-6728 ATX Mainboard
E-4-14
Core Center (for Pentium 4 CPU)
Click on the Core Center icon in the main menu and the Core Center program will
be enabled.
CoreCenter is just like your PC doctor that can detect, view and adjust the PC
hardware and system status during real time operation.
In the left side it shows the current system status including the Vcore, 3.3V, +5V and
12V. In the right side it shows the current PC hardware status such as the CPU &
system temperatures and all fans speeds.
When you click the red triangles in the left and right sides, two sub-menus will open
for users to adjust the thresholds of system to send out the warning messages.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MSI 865PE Neo3-F and is the answer not in the manual?

MSI 865PE Neo3-F Specifications

General IconGeneral
ChipsetIntel 865PE
SocketSocket 478
Supported CPUIntel Pentium 4 / Celeron
Front Side Bus800/533/400 MHz
Memory Slots4 x DIMM
Memory TypeDDR SDRAM
Max Memory4 GB
Expansion Slots1 x AGP 8X, 5 x PCI
Audio ChipsetRealtek ALC655
LAN Speed10/100Mbps
PS/22
Form FactorATX
Storage Interfaces2 x ATA100, 2 x SATA 1.5Gb/s
Audio Channels6 Channels
LAN ChipsetRealtek 8100C
USB Ports8 x USB 2.0 (4 rear, 4 via headers)
