MSI A520M PRO-C DASH User Manual

5
 
Continued from previous page


 1x 24-pin ATX main power connector
 1x 4-pin ATX 12V power connector
 4x SATA 6Gb/s connectors
 1x M.2 slot (M-Key)
 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2
USB 3.2 Gen 1 5Gbps ports)
 2x USB 2.0 connectors (support additional 4 USB 2.0 ports)
 1x 4-pin CPU fan connector
 1x 4-pin system fan connector
 1x Front panel audio connector
 2x System panel connectors
 1x Chassis Intrusion connector
 1x Serial port connector
 1x Parallel port connector
 1x TPM module connector
 1x Clear CMOS jumper
  4x EZ Debug LED
 NUVOTON NCT6687-R Controller Chip


 CPU/ System/ Chipset/ MOS/ PCI-E temperature detection
 CPU/ System fan speed detection
 CPU/ System fan speed control

 Micro-ATX Form Factor
 9.6 in. x 8.7 in. (24.4 cm x 22.0 cm)

 1x 256 Mb flash
 UEFI AMI BIOS
 ACPI 6.0, SMBIOS 2.8
 Multi-language
Continued on next page

MSI A520M PRO-C DASH Specifications

General

ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1866, 2133, 2400, 2667, 2800, 2933, 3000, 3066, 3200, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4600 MHz
Wi-Fi	No
LAN controller	Realtek RTL8111EPV
Ethernet interface type	Gigabit Ethernet
Component for	PC
Motherboard form factor	micro ATX
Number of mounting holes	6
Motherboard chipset family	AMD
Cables included	SATA
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
BIOS type	-
RAID levels	0, 1, 10
Supported storage drive interfaces	SATA III
Maximum resolution	4096 x 2160 pixels
Maximum graphics card memory	16000 MB
Processor socket	Socket AM4
Compatible processor series	AMD Ryzen

Weight and Dimensions

Depth	220 mm
Width	244 mm
