17
 

Mit diesem Anschluss können Sie das optionale serielle Schnittstelle mit dem
Einbausatze verbinden.
1
2 10
9
1 DCD 2 SIN
3 SOUT 4 DTR
5 Ground 6 DSR
7 RTS 8 CTS
9 RI 10 No Pin

Der Onboard CMOS Speicher (RAM) wird durch eine externe Spannungsversorgung
durch eine Batterie auf dem Motherboard versorgt, um die Daten der
Systemkonfiguration zu speichern. Wenn Sie die Systemkonfiguration löschen
wollen, müssen Sie die Steckbrücke für kurze Zeit umsetzen.
Daten
beibehalten
(Standardwert)
CMOS-Daten
löschen/ Reset des
BIOS

 Schalten Sie den Computer ab und ziehen Sie das Netzkabel ab.
 Verwenden Sie eine Steckbrücke, um für 5-10 Sekunden kurzzuschließen.
 Entfernen Sie die Steckbrücke von.
 Stecken Sie das Kabel Ihres Computers in die Steckdose hinein und schalten Sie
den Computer ein.

Diese LEDs zeigen den Status des Motherboards an.
CPU - CPU wird nicht erkannt oder ist fehlerhaft.
 - DRAM wird nicht erkannt oder ist fehlerhaft.
VGA - GPU wird nicht erkannt oder ist fehlerhaft.
 - Boot-Gerät wird nicht erkannt oder ist fehlerhaft.
