MSI A68HM User Manual

10
󴘭󸉕
SATA1~4: SATA 6Gb/s
   SATA 6Gb/s󱘈
󱘈SATA󳰛 󶪔 
SATA1
SATA3
SATA2
SATA4
󴱄󳞱
y SATA 90󳍿󱝤󱘕󸋍󳍿󳩵󴇝󳳇󲢀󸤒󳙫

y SATA󱘷󶔏󱿻󱘈󱨵󵏎󶃘󱣤
 󳰛󶪔 󷬥
JFP1JFP2: 
LED󳰛󶪔
1
2 10
9
JFP1
1 HDD LED + 2 Power LED +
3 HDD LED - 4 Power LED -
5 Reset Switch 6 Power Switch
7 Reset Switch 8 Power Switch
9 Reserved 10 No Pin
1
JFP2
1 Speaker - 2 Buzzer +
3 Buzzer - 4 Speaker +
HDD LED
RESET SW
HDD LED
HDD LED -
HDD LED +
POWER LED -
POWER LED +
POWER LED
JFP1

MSI A68HM Specifications

General

Form Factor	Micro ATX
Chipset	AMD A68H
CPU Socket	FM2+
Memory Slots	2 x DIMM
Maximum Memory	32 GB
Storage Interface	4 x SATA 6Gb/s
Expansion Slots	1 x PCIe 2.0 x1
Audio	Realtek ALC887
LAN	Realtek RTL8111G
Video Outputs	1 x HDMI
Memory Speed	2133/1866/1600
USB Ports	2 x USB 3.0 (rear) 6 x USB 2.0
