MSI A68HM - Jpwr1~2: 전원 커넥터; Jtpm1: Tpm 모듈 커넥터

12
󺦋󼐃
JPWR1~2: 󼕳󼐿 󼱓󺺔󼺟
󼓣 󼱓󺺔󼺟󻛫 󻸛󼐘󽋇󼍛 ATX 󼕳󼐿 󺩤󺭸 󼔔󼯇󻛫 󼍟󺨟󽋏 󻾇 󼓷󼀤󻀷󻁓.
24
131
12
JPWR1
1 +3.3V 13 +3.3V
2 +3.3V 14 -12V
3 Ground 15 Ground
4 +5V 16 PS-ON#
5 Ground 17 Ground
6 +5V 18 Ground
7 Ground 19 Ground
8 PWR OK 20 Res
9 5VSB 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 Ground
5
4 1
8
JPWR2
1 Ground 5 +12V
2 Ground 6 +12V
3 Ground 7 +12V
4 Ground 8 +12V
󼚀󼐃󻸛󽋜
󻠗󻉏 󼕳󼐿 󼱯󼓣󻮃󼓣 ATX 󼕳󼐿 󺩤󺭸 󼔔󼯇󼌿 󼎛󻦃󻛣󺧻 󼍟󺨟󻆇󼌣 󻟃󼓧󻩣󻉋󺥯 󼊷󼖄󼕰󼒫󻗋
󼔀󻅈󽋇󻀃󼜯 󽏄󼓧󽋇󻺧󼐃.
JTPM1: TPM 󻠗󻈷 󼱓󺺔󼺟
󼓣 󼱓󺺔󼺟󻀃 TPM (Trusted Platform Module) 󻠗󻈷󼌿 󼍟󺨟󻆘󻀷󻁓. 󼓿󻺧󽋋 󺸣󼐘󺩫 󻸛󼐘󻨄󼒯
TPM 󻩣󼊷 󽉻󻔚󽅫 󻺓󻟴󻺋󻛫 󼦧󼗟󽋇󻺧󼐃.
1
2 14
13
1 LPC Clock 2 3V Standby power
3 LPC Reset 4 3.3V Power
5 LPC address & data pin0 6 Serial IRQ
7 LPC address & data pin1 8 5V Power
9 LPC address & data pin2 10 No Pin
11 LPC address & data pin3 12 Ground
13 LPC Frame 14 Ground
