MSI AmethystM - Quick Components Identification

2-2
MS-7184 M-ATX Mainboard
Quick Components Guide
DDR DIMMs, p.2-7
Back Panel
I/O, p.2-10
JPW1, p.2-9
IDE1/2, p.2-12
ATX1, p.2-9
CFAN1, p.2-11
FDD1, p.2-11
SFAN1, p.2-11
JAUX1, p.2-14
J1394_1, p.2-15
PCI Express
Slot, p.2-18
PCI Slots,
p.2-18
JAUD1, p.2-14
JCD1, p.2-14
JFP1, p.2-16
JPWD1,p.2-17
JUSB1, JUSB2, p.2-16
SATA1~2,
p.2-13
JCMOS1,
p.2-17
CPU, p.2-3
JLPC1,p.2-15
