MSI B760 GAMING PLUS WIFI User Manual

17
Continued from previous column
Internal USB
Connectors
 1x USB 3.2 Gen 1 5Gbps Type-C front panel connector
(From B760 chipset)
 1x USB 3.2 Gen 1 5Gbps connector (From B760 chipset)
• Supports additional 2 USB 3.2 Gen 1 5Gbps ports
 2x USB 2.0 connectors (From Hub-GL850G)
• Supports additional 4 USB 2.0 ports
Fan Connectors
 1x 4-pin CPU fan connector
 1x 4-pin water-pump fan connector
 5x 4-pin system fan connectors
System Connectors
 1x Front panel audio connector
 2x System panel connectors
 1x Chassis Intrusion connector
 1x TPM module connector
 1x Parallel port connector
 1x Serial port connector
 1x TBT connector (Supports RTD3)
Jumpers  1x Clear CMOS jumper
LED Features
 4x EZ Debug LED
 1x 4-pin RGB LED connector
 2x 3-pin A-RAINBOW V2 (ARGB Gen2) LED connectors
Back Panel
Connectors
 1x PS/2 port
 4x USB 2.0 Type-A ports (From B760 chipset)
 1x DisplayPort
 1x HDMI™ port
 1x 2.5G LAN (RJ45) jack
 2x USB 3.2 Gen 2 10Gbps Type-A ports (From B760
chipset)
 1x USB 3.2 Gen 2 10Gbps Type-C port (From B760 chipset)
 2x Wi-Fi Antenna connectors
 5x Audio jacks
 1x Optical S/PDIF OUT connector
I/O Controller NUVOTON NCT6687 Controller Chip
Continued on next column

MSI B760 GAMING PLUS WIFI Specifications

General

Form Factor	ATX
Chipset	Intel B760
Socket	LGA 1700
Memory Slots	4
Max Memory	128GB
Memory Type	DDR5
PCIe 5.0 x16 Slot	1
PCIe 4.0 x16 Slot	1
PCIe 3.0 x1 Slot	2
M.2 Slots	2
SATA Ports	4
Networking	2.5G LAN
Audio	Realtek ALC897
RGB Headers	2
