37

󳲜󶬖
󴳇󳠴
󳘗󳲜󶬖󴨟󳲜󶬖󲝉󲁹󴡇󲑟󳵊
󱫮 
󱱨󱯱󹩙

 󱥯󲁢󲁿  󱥯󲁢󲁿
1 VCC 2 VCC
3 USB0- 4 USB1-
5 USB0+ 6 USB1+
7 Ground 8 Ground
9 No Pin 10 NC
1
2 10
9

󳲜󶬖󸒏󶩆
󲀏󵒵󱚘
 󱥯󲁢󲁿  󱥯󲁢󲁿
1 SPI Power 2 SPI Chip Select
3
Master In Slave Out
(SPI Data)
4
Master Out Slave In
(SPI Data)
5 Reserved 6 SPI Clock
7 Ground 8 SPI Reset
9 Reserved 10 No Pin
11 Reserved 12 Interrupt Request
12
12 11
