MSI B760 GAMING PLUS WIFI

21
Back Panel Connectors
11 22 33 44 55
77 88 99 1010 1111
66
Item Description
1 PS/2 keyboard/ mouse port
2 DisplayPort
3 2.5 Gbps LAN (RJ45) port
4 USB 2.0 Type-A ports (From B760 chipset)
5 Wi-Fi Antenna connectors
6 Audio jacks
7 USB 2.0 Type-A ports (From B760 chipset)
8
HDMI™ port
9 USB 3.2 Gen 2 10Gbps Type-A ports (From B760 chipset)
10 USB 3.2 Gen 2 10Gbps Type-C port (From B760 chipset)
11 Optical S/PDIF Out connector
