17
Fortsetzung der vorherigen Spalte
Interne USB
Anschlüsse
1x USB 3.2 Gen 1 5Gbit/s Typ-C Frontplattenanschluss
(vom B760 Chipsatz)
1x USB 3.2 Gen 1 5Gbit/s Anschluss (vom B760 Chipsatz)
Unterstützt zusätzliche 2 USB 3.2 Gen 1 5GBit/s
Anschlüsse
2x USB 2.0 Anschlüsse (vom Hub-GL850G)
Unterstützt zusätzliche 4 USB 2.0 Anschlüsse
Stromanschlüsse
für Lüfter
1x 4-poliger CPU-Lüfter-Stromanschluss
1x 4-poliger Anschluss für die Wasserpumpe
5x 4-polige System-Lüfter-Anschlüsse
Systemanschlüsse
1x Audioanschluss des Frontpanels
2x System-Panel-Anschlüsse
1x Gehäusekontaktschalter
1x TPM Anschluss
1X Parallele Schnittstelle
1x Serieller Anschluss
1x TBT Anschluss (Unterstützt RTD3)
Steckbrücke 1x Clear CMOS Steckbrücke
LED Funktionen
4x EZ Debug LED
1x 4-poliger RGB LED Anschluss
2x 3-polige A-RAINBOW V2 (ARGB Gen2) LED Anschlüsse
Hintere Ein-/ und
Ausgänge
1x PS/2 Anschluss
4x USB 2.0 Typ-A Anschlüsse (vom B760 Chipsatz)
1x DisplayPort
1x HDMI™ Anschluss
1x 2,5Gbit/s LAN (RJ45) Anschluss
2x USB 3.2 Gen 2 10Gbit/s Typ-A Anschlüsse (vom B760
Chipsatz)
1x USB 3.2 Gen 2 10Gbit/s Typ-C Anschluss (vom B760
Chipsatz)
2x Wi-Fi Antennenanschlüsse
5x Audiobuchsen
1x Optischer S/PDIF-Ausgang Anschluss
Fortsetzung auf der nächsten Spalte
