MSI B760M GAMING PLUS WIFI User Manual

18
Continued from previous column
Fan Connectors
∙ 1x 4-pin CPU fan connector
∙ 1x 4-pin water-pump fan connector
∙ 2x 4-pin system fan connectors
System Connectors
∙ 1x Front panel audio connector
∙ 2x System panel connectors
∙ 1x Chassis Intrusion connector
∙ 1x TPM module connector
∙ 1x Serial port connector
Jumpers
∙ 1x Clear CMOS jumper
LED Features
∙ 4x EZ Debug LED
∙ 1x 4-pin RGB LED connector
∙ 2x 3-pin A-RAINBOW V2 (ARGB Gen2) LED connectors
Back Panel
Connectors
∙ 1x PS/2 keyboard /Mouse combo port
∙ 2x USB 2.0 Type-A ports (From B760 chipset)
∙ 2x DisplayPort
∙ 2x HDMI™ ports
∙ 2x USB 3.2 Gen 1 5Gbps Type-A ports (From B760 chipset)
∙ 1x 2.5G LAN (RJ45) jack
∙ 2x USB 3.2 Gen 2 10Gbps Type-A ports (From B760
chipset)
∙ 2x Wi-Fi Antenna connectors
∙ 3x Audio jacks
I/O Controller NUVOTON NCT6687D Controller Chip
Hardware Monitor
∙ CPU/ System/ Chipset temperature detection
∙ CPU/ System/ Pump fan speed detection
∙ CPU/ System/ Pump fan speed control
Form Factor
∙ Micro-ATX Form Factor
∙ 9.6 in. x 9.6 in. (244 mm x 244 mm)
Continued on next column

MSI B760M GAMING PLUS WIFI Specifications

General

Form Factor	Micro-ATX
Chipset	Intel B760
Socket	LGA 1700
Memory Slots	4
Maximum Memory	128 GB
Memory Type	DDR5
Wireless	Wi-Fi 6E
RAID Support	RAID 0, 1, 5, 10
M.2 Slots	2
SATA Ports	4
Bluetooth	5.3
Audio	Realtek ALC897
LAN	1x 2.5GbE
PCIe Slots	1 x PCIe 3.0 x1
