MSI C236M WORKSTATION - Specifications

15
Specifications
Specifications
CPU
Supports Intel
®
Xeon
®
E3-1200 v5 series processors, Core™
i3 processors, and Intel
®
Pentium
®
and Celeron
®
processors
for Socket LGA1151
Chipset
Intel
®
C236 Chipset
Memory
y 4x DDR4 memory slots, support up to 64GB
 Supports DDR4 2133 MHz
y Dual channel memory architecture
y Supports ECC, un-buffered memory*
y Supports Intel
®
Extreme Memory Profile (XMP)**
** DDR4 2133 MHz and higher memory modules will only run at maximum of
DDR4 2133 MHz on XMP mode due to Intel
®
chipset limitation.
Expansion Slots
y 2x PCIe 3.0 x16 slots (support x16/x4)*
y 2x PCIe 3.0 x1 slots
* The PCI_E4 slot will only run PCIe 3.0 x2 speed when the PCI_E3 slot is
installed a device.
Onboard Graphics
y 1x HDMI
™
port, supports a maximum resolution of
4096x2160@24Hz, 2560x1600@60Hz
y 1x VGA port, supports a maximum resolution of
2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz
y 1x DVI-D port, supports a maximum resolution of
1920x1200 @60Hz
Multi-GPU y Supports 2-Way AMD
®
CrossFire
™
Technology
Storage
Intel
®
C236 Chipset
y 6x SATA 6Gb/s ports
y 1x SATAe port*
y Supports RAID 0, RAID 1, RAID 5 and RAID 10
y Supports Intel
®
Smart Response Technology for Intel
Core
™
processors.
* SATAe port is backward compatible with SATA.
USB
Intel
®
C236 Chipset
y 8x USB 3.1 Gen1 (SuperSpeed USB) ports (4 ports on the
back panel, 4 ports available through the internal USB
connectors)
y 4x USB 2.0 (High-speed USB) ports (2 ports on the
back panel, 2 ports available through the internal USB
connectors)
Continued on next page
