CX600（MS-1682）Disassemble Guide
7、SEPARATE UPPER CASE AND LOWER CASE
7.3：Remove the 2 screws(M2*3mm) that stabilize
the hinge Cap
Attention: the screw driver torque is 1.5-2.0Kgf-cm
Component P/N Qty
Screw E43-1203003-H29 2
7.4 ： Remove the 4 screws(M2.5*5mm) that
stabilize the hinge
Attention: the screw driver torque is 3.0-3.5Kgf-cm
Component P/N Qty
Screw E43-1255007-H29 4
