CX600（MS-1682）Disassemble Guide
7、SEPARATE UPPER CASE AND LOWER CASE
7.1：Remove the 2 screws(M2*3mm);
Attention: the screw driver torque is: 1.5-2.0Kgf-cm
Component P/N Qty
Launch board
607-1682B-01S 1
Screw E43-1203003-H29 2
7.2：First release the connector that stabilize the
cable, then remove Launch board according to the
direction that pic shows;
