SLotS
PCIE (Perpheral Component Interconnect Express) Slot
The PCI Express slot supports the PCI Express nterface expanson card.
PCI Express x16 Slot
PCI Express x1 Slot
Important
When addng or removng expanson cards, make sure that you unplug the power sup-
ply 󰘰rst. Meanwhle, read the documentaton for the expanson card to con󰘰gure any
necessary hardware or software settngs for the expanson card, such as jumpers,
swtches or BIOS con󰘰guraton.
