MSI H610TI-S03 User Manual

6
Continued from previous page
System Connectors
 1x Front panel audio connector
 1x System panel connector
 1x TPM module connector
 1x Serial port connector
 1x Touch panel connector
 1x LVDS connector
 1x Audio Amplifier connector
 1x Digital microphone connector
 1x FPD brightness connector
 1x Panel display switch connector
Jumpers
 1x Clear CMOS jumper
 1x Panel voltage selection header
 1x Backlight inverter voltage selection header
LED Features  4x EZ Debug LED
Back Panel
Connectors
For H610 TI-S03
 1x DC IN connector (DC tip size: 6.5 x 2.5 mm)
 1x HDMI port
 1x Serial port
 1x Clear CMOS button
 1x LAN (RJ45) port
 2x USB 3.2 Gen2 10Gbps Type-A ports
 2x USB 3.2 Gen1 5Gbps Type-A ports
 2x audio jacks (1 Line out + 1 Mic in)
For H610 TI-S01
 1x DC IN connector (DC tip size: 6.5 x 2.5 mm)
 1x HDMI port
 1x DisplayPort port
 1x LAN (RJ45) port
 1x USB 3.2 Gen2 10Gbps Type-A port
 1x USB 3.2 Gen2 10Gbps Type-C port
 2x USB 3.2 Gen1 5Gbps Type-A ports
 2x audio jacks (1 Line out + 1 Mic in)
Continued on next page

MSI H610TI-S03 Specifications

General

Brand	MSI
Model	H610TI-S03
Category	Motherboard
Language	English
