MSI MEG X570S UNIFY-X MAX User Manual

29
Overview of Components
Component Contents
Port Name Port Type Page
AM4 Socket Processor Socket 30
BIOS_SW1 Multi-BIOS Switch 43
CPU_FAN1, PUMP_FAN1,
SYS_FAN1~6
Fan Connectors 41
CPU_PWR1~2, ATX_PWR1 Power Connectors 36
DIMMA1, DIMMB1 DIMM Slots 31
JAUD1 Front Audio Connector 38
JBAT1 Clear CMOS (Reset BIOS) Jumper 44
JCI1 Chassis Intrusion Connector 42
JCORSAIR1 CORSAIR Connector 47
JDASH1 Tuning Controller connector 42
JFP1, JFP2 Front Panel Connectors 35
JLN1 Low Temperature Booting Jumper 38
JOC_FS1 Safe Boot Jumper 37
JRAINBOW1~2 Addressable RGB LED connectors 46
JRGB1 RGB LED connector 45
JTPM1 TPM Module Connector 40
JUSB1 USB 3.2 Gen 2 Type-C Connector 39
JUSB2~3 USB 3.2 Gen1 Connectors 39
JUSB4~5 USB 2.0 Connectors 40
M2_1~6 M.2 Slots (Key M) 33
PCI_E1~2 PCIe Expansion Slots 32
POWER1, RESET1 Power Button, Reset Button 44
SATA1~6 SATA 6Gb/s Connectors 35
T_SEN1~2 Thermal Sensor Connectors 37
W_FLOW1 Water Flow Meter Connector 37

MSI MEG X570S UNIFY-X MAX Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Maximum number of SMP processors	1
Non-ECC	Yes
Memory channels	Dodeca-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1866, 2133, 2400, 2667, 2800, 2933, 3000, 3066, 3200, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4533, 4600, 4733, 4800, 4866, 5000, 5100, 5300 MHz
RAID levels	0, 1, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, PCI Express, PCI Express 3.0, PCI Express 4.0, SATA III
Parallel processing technology support	Crossfire
Number of SATA III connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
LAN controller	Realtek RTL8125
Ethernet interface type	2.5 Gigabit Ethernet
Audio chip	Realtek ALC4080
Cooling type	Active
Component for	PC
Motherboard chipset	AMD X570
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64
BIOS type	UEFI AMI
System Management BIOS (SMBIOS) version	3.4
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	244 mm
Width	305 mm
