Specifications

CPU

∙ Supports AMD Ryzen™ 5000 Series, 5000 G-Series 4000

G-Series, 3000 Series, 3000 G-Series, 2000 Series and 2000

G-Series desktop processors*

∙ Supports Socket AM4

* Please go to msi.com to get the newest support status as new processors are

released.

Chipset AMD X570 Chipset

Memory

∙ 2x DDR4 memory slots, support up to 64GB

∙ Supports 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/

3200 MHz by JEDEC*

∙ Max frequency by A-XMP OC mode:

▪ For Ryzen™ 5000 G-Series & 4000 G-Series

processors

▫ 1DPC 1R Max speed up to 5300 MHz (support

overclocking up to 5800 MHz)

▫ 1DPC 2R Max speed up to 4266 MHz (support

overclocking up to 4600 MHz)

▪ For Ryzen™ 5000 Series & 3000 Series processors

▫ 1DPC 1R Max speed up to 5300 MHz

▫ 1DPC 2R Max speed up to 4266 MHz

∙ Supports Dual-Channel mode

∙ Supports non-ECC, un-buffered memory

*Please refer to www.msi.com for more information on compatible memory

Expansion Slots

∙ Supports PCIe 4.0 / PCIe 3.0

▪ PCIe 4.0 is available only on AMD Ryzen™ 5000 Series

and 3000 Series desktop processors

∙ 2x PCIe x16 slots (PCI_E1 from processor, PCI_E2 from

X570 chipset)*

▪ Support x16/ x8 for AMD Ryzen™ 5000 Series, 5000

G-Series, 4000 G-Series, 3000 Series and 2000 Series

desktop processors

▪ Support x8/ x8 for AMD Ryzen™ 2000 G-Series and

3000 G-Series desktop processors

* PCI_E1~2, M2_3~6 and SATA5~6 share the same bandwidth. Please see the

page 32 for more details.

Multi-GPU Supports AMD CrossFire™ Technology

LAN 1x Realtek® RTL8125B 2.5 Gbps LAN controller

Continued on next page
