MSI MEG X570S UNIFY-X MAX User Manual

17
Specifications
Continued from previous page
Audio
Realtek® ALC4080 Codec
∙ 7.1-Channel High Definition Audio
∙ Supports S/PDIF output
Storage
∙ 6x SATA 6Gb/s ports (From X570 chipset)*
∙ 6x M.2 slots (Key M)
▪ Supports PCIe 4.0 / PCIe 3.0
▫ PCIe 4.0 is available only on AMD Ryzen™ 5000
Series and 3000 Series desktop processors
▪ M2_1 (From processor)
▫ Supports SATA 6Gb/s and PCIe M.2 2260/ 2280
storage devices
▪ M2_2 (From X570 chipset)
▫ Supports PCIe M.2 2280/ 22110 storage devices
▪ M2_3* (From processor)
▫ Supports PCIe M.2 2280/ 22110 storage devices
▪ M2_4* (From processor)
▫ Supports PCIe M.2 2260/ 2280 storage devices
▪ M2_5* (From X570 chipset)
▫ Supports PCIe M.2 2280/ 22110 storage devices
▪ M2_6* (From X570 chipset)
▫ Supports SATA 6Gb/s and PCIe M.2 2280/ 22110
storage devices
* PCI_E1~2, M2_3~6 and SATA5~6 share the same bandwidth. Please see the
page 32 for more details.
RAID
AMD X570 Chipset
∙ Supports RAID 0, RAID 1 and RAID 10
Continued on next page

MSI MEG X570S UNIFY-X MAX Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Maximum number of SMP processors	1
Non-ECC	Yes
Memory channels	Dodeca-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1866, 2133, 2400, 2667, 2800, 2933, 3000, 3066, 3200, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4533, 4600, 4733, 4800, 4866, 5000, 5100, 5300 MHz
RAID levels	0, 1, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, PCI Express, PCI Express 3.0, PCI Express 4.0, SATA III
Parallel processing technology support	Crossfire
Number of SATA III connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
LAN controller	Realtek RTL8125
Ethernet interface type	2.5 Gigabit Ethernet
Audio chip	Realtek ALC4080
Cooling type	Active
Component for	PC
Motherboard chipset	AMD X570
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64
BIOS type	UEFI AMI
System Management BIOS (SMBIOS) version	3.4
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	244 mm
Width	305 mm
